The ADS Beyond 300 is a post-mounted over-the-patient delivery system built around accessible controls, serviceable utilities and a clean clinical workflow.

Key features

• Beyond control head with standard touchpad, cast-aluminum base and double-pivot head
• Three automatic handpiece positions with individual water-coolant controls
• Post-mounted utility with city or bottled water and air/water quick disconnect
• Assistant tray with touchpad, two HVE valves, one saliva ejector and one syringe
• Post-mounted LED light with sensor control
• Electrical: AC 110V ±22V, 60 Hz
• Water pressure: 29 to 58 psi
• Input air pressure: 72.5 to 101.5 psi with at least 50 L/min airflow

Planning note: Final mounting, handpiece positions, utility requirements, accessories, delivery and installation are confirmed before we quote.
